TAPP All-weather USB power port with Universal Mount and TAPP CAPP
TAPP All-weather USB power port with Universal Mount and TAPP CAPP
Couldn't load pickup availability
- This compact, easy to mount, all-weather 2.1 amp USB Power Port is the answer for powering and charging your USB devices including cell phones, smart phones, most GPS units, MP3 players and most digital cameras.
- It mounts easily to any surface using the patented Universal Mounting System.
- Ultra-low quiescent current allows direct connection to the battery without concern about discharging the battery over time.
- A removable, replaceable Brulloy™ seal cap protects the power port from dust and water. USB cable connection is all-weather when used with a 3BR Powersports’ patented TAPP CAPPed cable.
- TAPP CAPP included in kit
- Specifications
- Input Voltage: 12VDC (8VDC to 18VDC)
- USB (Output) Voltage: 5V ±.25V. Quick Charge up to 12VDC
- Output Current: 2.1A Max. Quick Charge 18W Max
- TAPP family of USB power ports are the ONLY powersports USB power port that are all-weather when a USB cable is plugged in*
- Low no-load power draw (1.7mA) allows direct connection to the vehicle battery. Makes installation on CanBus bikes like BMW and Ducati a snap.
- Quick Charge 3.0 technology provides up to 18W of power for fast charging of Android devices. iPhone and iPad also charge at full rate.
- Installation kit includes 3BR Powersports Universal Mounting System and TAPP CAPP™.
- Weatherproof up to full water wash down.
- Removable/replaceable seal cap.
*When cable is equipped with TAPP CAPP™ (included in kit)
3BR's TAPP products are still -- to my knowledge -- the only USB port systems that are rainproof WHILE IN USE. I've used 3BR's Panel TAPP ports on four motorcycles now, and this is my first use of the Universal Mount (on another moto, a Royal Enfield Meteor 350). Same top-notch quality, in-use rainproof, and now an always-on port for the parasitic draw is both negligible and a stated value -- try finding all those attributes in another vendor's product.
Cheers,
Bill P.
I installed this on my motorcycle a few weeks ago. The install was fairly easy, I removed the gas tank and ran the cord under the tank to keep everything clean. I’ve used the charger on a few longer trips and it has worked great so far!
So this purchase was to replace the 3BR unit purchased in 2019 and that died (full of rain water) in early 2025 (leaving me GPS-less in a driving rainstorm in the middle of a National Forest). So it seems that the "waterproof" connector will eventually need replacing to remain waterproof.(it's garage kept when not out on a trip). Also be advised that you will need to add another foot or so of wiring to reach the battery/fuse box on a 2001-2017 Goldwing from the handlebars.
Marty, It sounds as though you did not have a TAPP CAPP on your GPSr cable.
TAPP all-weather power port is the only USB power port that is weatherproof when a cable is plugge in. BUT, the cable MUST have our patented TAPP CAPP on it.
Also note that the TAPP is 'weatherproof' not waterproof. To be waterproof it must withstand being submerged to a depth of 1 meter for 30 minutes.
TAPP will withstand heavy water washdown but cannot be submerged.
There should be no need to add cable lenght to reach the Gold WIng battery. It is in the middle of the bike so 5 ft of cable should be plenty. I have not had any other GW owners report that they needed to add cable.
Excellent customer service! These USB ports are well made and include everything you need to plumb weatherproof USB power. Very happy with my purchase! Buy with confidence!
This works perfect. Great fit where the old lighter port went. It creates a dry and sealed USB port that is secure. I am not sure why Harley (or any manufacture) is still using cigarette light ports. When they could be putting a USB port like this on them. Highly recommend this port. It was everything I hoped it would be.
